This configuration allows a connection with more than one Hitachi PLC. For this, use an RS-485 network as shown on the next figure.
PLC network with COMM modules
Hitachi provides several models of COMM modules allowing this type of network configuration, such as Comm-H, Pil-H, and Actinet-S. Addressing, in this case, is via Office Number, which represents the station number on the network. For more information, please check topic Tag Reference.
NOTE |
The COMM module must be configured to work with a Station Number, because this is how this Driver communicates. This Station Number is also known as Office Number. The communication parameters of this module must be 1 (one) stop bit, 7 (seven) data bits, even parity, and compatible baud rate. |
